Design incorporates naturally occurring physics by countering centrifugal forces to blade air load reactions.
Fan features scientifically calculated fixed "Droop Angle" and twisted/tapered blade design.
Efficient blade design allows lower RPM's for reduced noise/quiet operation.
Manufactured on new computer controlled, automated machinery.
Diameters available from 4' -14’ with Uniform velocity across blade length.
Small hub reduces/eliminates dead spots.
Guaranteed air-side performance & Guaranteed noise predictions.
Availability in odd or even blade quantities expands fan options and reduces costs.
1/3 band noise calculations and performance curves available free of charge.
Easily installed by one person.
Single replacement blades available.
Short lead times, quick deliveries.
Durable packaging for shipment.
Emergency service/shipments available.
Detailed, easy to follow installation instructions.
Blade Skin: Corrosion resistant, durable (high fatigue strength) 5052 H38 Aluminium.
Hub: Ultra high strength plate hub featuring aircraft grade 6061 T-6 Aluminium.
Center Section: Aircraft grade, corrosion resistant 356-T6 cast Aluminium featuring excellent tensile and yield properties.
Hardware: Zinc Plated Bolts: Grade 5, ASTM Specification.A449, Type 1, SAE ]429.
Nuts: Grade 5, IFI Specification 100-107.
Rivets: A combination of solid rivets and special high strength mono bolts.
Bushing: Split taper QD bushing of cast ductile Iron.
No two jobs are the same. Meaning every job is designed and built as a unique product to your exact requirements.
With our own dedicated supply chain, it means your deliveries will always be on time, to help fulfill any tight deadlines.
All of our PowerFlo Fans are designed with unique control systems in mind. So please speak to our sales department about CE-Air control systems.
Every single PowerFlo Fan is built as if it were our own. Our staff have over 100 years combined experience of building our kit, so you can be sure each one is perfect.
